Exposed tactical turrets built for dialing elevation and windage allow quick and precise bullet drop and wind drift compensation at extended ranges. When we say precise - we mean it. These turrets track better than any Bloodhound and reliably return to zero every time. A zero-reset feature lets you re-index the zero reference marks on both turrets after sight in, while fiber optic rotation indicators integrated into the turrets provide a visual cue of your turrets position.
VMR-1 (MOA)
Designed to maximize long distance shooting and ranging abilities, the VMR-1 MOA reticle can be used to effectively determine ranges, holdovers, windage corrections and moving target leads.
| SKU | I-20393 |
| MPN | DBK-10023 |
| Reticle | VMR-1 (MOA) |
| Magnification | 3-9x |
| Objective Lens Diameter | 40 mm |
| Eye Relief | 3.9 inches |
| Field of View | 33.7-11.3 ft/100 yds |
| Tube Size | 1 inch |
| Turret Style | Tactical |
| Adjustment Graduation | 1/4 MOA |
| Travel Per Rotation | 12 MOA |
| Max Elevation Adjustment | 80 MOA |
| Max Windage Adjustment | 80 MOA |
| Parallax Setting | 100 yards |
| Length | 12.5 inches |
| Weight | 15.9 oz |
| OPTICAL FEATURES |
| XD Lens Elements | Extra-low dispersion (XD) glass increases resolution and color fidelity, resulting in crisp, sharp images. |
| XR Fully Multi-Coated | Proprietary coatings increase light transmission with multiple anti-reflective coatings on all air-to-glass surfaces. |
| Second Focal Plane Reticle | Scale of reticle maintains the same ideally-sized appearance. Listed reticle subtensions used for estimating range, holdover and wind drift correction are accurate at the highest magnification. |
| |
| CONSTRUCTION FEATURES |
| Tube Size | 1 inch diameter tube offers a versatile blend of adjustment, size and weight for a wide variety of shooting applications. |
| Aircraft-Grade Aluminum | Constructed from a solid block of aircraft-grade aluminum for strength and rigidity. |
| Waterproof | O-ring seals prevent moisture, dust and debris from penetrating the binocular for reliable performance in all environments. |
| Fogproof | Nitrogen gas purging prevents internal fogging over a wide range of temperatures. |
| Shockproof | Rugged construction withstands recoil and impact. |
| Hard Anodized Finish | Highly durable hard-coat anodization provides a low-glare matte surface and helps camouflage the shooter's position. |
| Precision-Glide Erector System | This system ensures the components in the zoom lens mechanism glide smoothly and cleanly through all magnification ranges. |
| Exposed Tactical-Style Turrets | Provide fast, accurate and easily read elevation and windage adjustments. |
| |
| CONVENIENCE FEATURES |
| Radius Bar | Fiber optic turret rotation indicator provides a highly visible and tactile point of reference for turret rotations. |
| Magnification Rib | The raised rib on the magnification ring facilitates fast magnification changes in the heat of action. |
