The gap between tactical mid- and long-range shooting is gone. Top off your carbine or DMR rifle with a first focal plane optic thats versatile, tough, ultra-clear at any magnification, and specifically designed for rapid adjustment in fast-changing target scenarios.
Optical Features
- First Focal Plane Reticle Scale of reticle remains in proportion to the zoomed image. Constant subtensions allow accurate holdover and ranging at all magnifications.
- XD Optical System Extra-low dispersion (XD) glass increases resolution and color fidelity, resulting in
- Illuminated Reticle Provides precise aiming under low-light conditions.
- RevStop Zero System Patented streamlined design offers a toolless zero stop for rock-solid return to zero after turret adjustments.
- Glass-Etched Reticle Allows for intricate reticle design. Protected between two layers of glass for optimum durability and reliability.
- Fully Multi-Coated Lenses Anti-reflective coatings on all air-toglass surfaces provide increased light transmission for greather clarity and low-light performance.
Construction Features
- ArmorTek Ultra-hard, scratch-resistant coating protects exterior lenses from scratches, oil and dirt.
- Single-Piece Tube Maximizes alignment for improved accuracy and optimum visual performance, as well as ensures strength and waterproofness.
- Aircraft-Grade Aluminum Constructed from a solid block of aircraft-grade aluminum for strength and rigidity.
- Low Glare Matte Black Annodize Corrosion and wear resistant anodization provides low-glare matte surface and helps camouflage the shooter's position.
- Nitrogen Gas Purged Gas purged and O-ring sealed for fogproof and waterproof performance in all conditions.
- Waterproof Designed to withstand harsh weather conditions
- Fogproof Nitrogen gas purging prevents internal fogging over a wide range of temperatures
- Shockproof Designed to withstand the highest levels of recoil and impact.
Convenience Features
- Fast Focus Eyepiece Allows quick and easy reticle focusing
- Throw Lever The included throw lever can be installed for quick and easy magnification adjustments
SKU | ISS6525 | ISS6524 |
MPN | SE-31801 | SE-31802 |
Magnification | 3-18x | 3-18x |
Objective Lens Diameter | 44 mm | 44 mm |
Reticle | EBR-7C (MOA) | EBR-7C (MRAD) |
Eye Relief | 3.8" | 3.8" |
Turret Style | Exposed Elevation Capped Windage | Exposed Elevation Capped Windage |
Tube Size | 34 mm | 34 mm |
Adjustment Graduation | 1/4 MOA | .1 MRAD |
Parallax Setting | 10 yds | 10 yds |
Max Windage Adjustment | 62 MOA | 18 MRAD |
Max Elevation Adjustment | 154 MOA | 45 MRAD |
Travel Per Rotation | 25 MOA | 10 MRAD |
Length | 13.3" | 13.3" |
Weight | 27.3 oz | 27.3 oz |
Field of View | 39.3' - 6.7' | 39.3' - 6.7' |
