Its 18x magnification makes the Z6 3-18x50 P BT L ideal for long-range shooting. Not to mention that the 3x magnification offers you the assurance of a large field of view. HD optics and lateral parallax correction guarantee you a faultless image. The ballistic turret can be separately adjusted to your personal requirements, allowing you to stay on target at different distances.
SKU | I-20209 | I-20210 |
MPN | 59610 | 59618 |
Mount-Type | Ring-Mount | Ring-Mount |
Reticle | Plex | 4W |
OBJECTIVE |
Magnification | 3-18x |
Effective Objective Lens Diameter | 29.0-50 mm |
Exit Pupil Diameter | 9.5-2.8 mm |
Exit Pupil Distance | 95 mm |
Field of View | 39.9-6.6 ft/100 yds |
Field of View | 7.6-1.3 |
Field of View Apparent | 22.8 |
Diopter Adjustment | -3 to +2 dpt |
Light Transmission | 90 % |
Twilight Factor Acc. to ISO 14132-1 | 8.5-30 |
Parallax Correction | 55- yd |
| |
MEASUREMENT |
Impact Point Correction Per Click | 0.36/10 / 0.18/5 |
Max. Elevation / Windage Adjustment Range | 64.8-36 / 1.8-1 |
| |
DIGITAL |
Objective Filter Thread | M 52x0.75 |
| |
SIZE & WEIGHT |
Length | 15 in |
Weight | 21 oz |
Central Tube Diameter | 1.18 in |
| |
ENVIRONMENT & CONDITIONS |
Functional Temperature | -4 to +131 F |
Storage Temperature | -22 to +158 F |
Submersion Tightness | 13 ft / 4 m water depth (inert gas filling) |
