Its high-luminosity optics mean you can also hunt at dawn and dusk and in poor light. The ballistic turret can be separately adjusted to your personal requirements, allowing you to stay on target at different distances.
SKU | 22778 | 22828 |
MPN | 69769 | 69771 |
Mount-Type | Ring-Mount | Ring-Mount |
Reticle | Plex-I | 4W-I |
OBJECTIVE |
Magnification | 2.4-12x |
Effective Objective Lens Diameter | 23-50 mm |
Exit Pupil Diameter | 10-4.1 mm |
Exit Pupil Distance | 95 mm |
Field of View at 100 Yds/ 100 m | 45.9-9 ft/100 yds |
Field of View Degrees | 8.7-1.75 |
Field of View Apparent | 21.5 |
Diopter Adjustment | -3 to +2 dpt |
Light Transmission | 92 % |
Paralax Correction | - |
| |
MEASUREMENT |
Impact Point Correction Per Click | 0.25 / 7 |
Max. Elevation / Windage Adjustment Range | 90/50 / 2.5/1.4 |
| |
DIGITAL |
Objective Filter Thread | M 52x0.75 |
| |
SIZE & WEIGHT |
Length | 13.1 in |
Weight | 17.7 oz |
Central Tube Diameter | 1 in |
| |
ENVIRONMENT & CONDITIONS |
Functional Temperature | -4 to +131 F |
Storage Temperature | -22 to +158 F |
Submersion Tightness | 13 ft / 4 m water depth (inert gas filling) |
